BVA Hydraulics Electric Hydraulic Power Units
★★★★⯨4.8 (39 reviews)Overview
The BVA Hydraulics Electric Hydraulic Power Units is built for industrial and material-handling work. Specifications include max pressure rating (2nd stage) of 10,000 psi for all models, model family of 501-1,503 ton. Request a quote for bulk pricing. Freight and lead time are confirmed at checkout, and business leasing is available.
Specifications
| Motor | Electric industrial induction motor, single phase (standard 115V, 60Hz, NEMA 5-15P plug) |
| Max Pressure Rating (2nd stage) | 10,000 psi for all models |
| Operation | Two-speed (fast advance, then high-pressure) |
| Noise | Quiet operation, meets OSHA 80 dBA regulation |
| Brand | BVA Hydraulics |
| Shipping | Free · freight ETA at checkout |
Specifications by size
Manufacturer-published figures for each of the 11 sizes in this range.
Show all 11 sizes
- Model family:
- PE0501T
- Oil Output Flow Rate:
- 293 in3/min 1st stage / 18 in3/min 2nd stage
- 1st Stage Pressure:
- 350 psi
- Current Draw:
- 9A
- Weight:
- 59.5 lbs
- Model family:
- PEW0501T (pendant variant of PE0501T)
- Oil Output Flow Rate:
- 293 in3/min 1st stage / 18 in3/min 2nd stage
- 1st Stage Pressure:
- 350 psi
- Current Draw:
- 9A
- Weight:
- ~59.5 lbs (pendant adds negligible weight)
- Model family:
- PEM0501T
- Oil Output Flow Rate:
- 293 in3/min 1st stage / 18 in3/min 2nd stage
- 1st Stage Pressure:
- 350 psi
- Current Draw:
- 9A
- Weight:
- 59.5 lbs
- Model family:
- PEWM0501T (pendant variant of PEM0501T)
- Oil Output Flow Rate:
- 293 in3/min 1st stage / 18 in3/min 2nd stage
- 1st Stage Pressure:
- 350 psi
- Current Draw:
- 9A
- Model family:
- PE1002T
- Oil Output Flow Rate:
- 397 in3/min 1st stage / 37 in3/min 2nd stage
- 1st Stage Pressure:
- 700 psi
- Current Draw:
- 12A
- Weight:
- 70.5 lbs
- Model family:
- PEW1002T (pendant variant of PE1002T)
- Oil Output Flow Rate:
- 397 in3/min 1st stage / 37 in3/min 2nd stage
- 1st Stage Pressure:
- 700 psi
- Current Draw:
- 12A
- Model family:
- PEM1002T
- Oil Output Flow Rate:
- 397 in3/min 1st stage / 37 in3/min 2nd stage
- 1st Stage Pressure:
- 700 psi
- Current Draw:
- 12A
- Weight:
- 70.5 lbs
- Model family:
- PEWM1002T (pendant variant of PEM1002T)
- Oil Output Flow Rate:
- 397 in3/min 1st stage / 37 in3/min 2nd stage
- 1st Stage Pressure:
- 700 psi
- Current Draw:
- 12A
- Model family:
- PEW1503T (pendant variant of PE1503T)
- Oil Output Flow Rate:
- 476 in3/min 1st stage / 61 in3/min 2nd stage
- 1st Stage Pressure:
- 700 psi
- Current Draw:
- 17A
- Model family:
- PEM1503T
- Oil Output Flow Rate:
- 476 in3/min 1st stage / 61 in3/min 2nd stage
- 1st Stage Pressure:
- 700 psi
- Current Draw:
- 17A
- Weight:
- 88.5 lbs
- Model family:
- PE1503T
- Oil Output Flow Rate:
- 476 in3/min 1st stage / 61 in3/min 2nd stage
- 1st Stage Pressure:
- 700 psi
- Current Draw:
- 17A
- Weight:
- 88.5 lbs
