Caldwell Dura-Lite Composite Adjustable Lifting Beams

Authorized Dealer

1/4–3 ton WLL by model; one rating per model
Hook spreads adjust 12–144 in across the series
Composite beam; non-conductive, will not rust
ASME B30.20, Design Category B, Service Class 4

From $1,518

From $63/mo with Financing & Leasing · won't affect your credit

●Ships in 5-10 business days; we confirm your freight ETA before dispatch

Min-Max. Spread x Capacity | Product Code

Choose Min-Max. Spread x Capacity | Product Code before adding to cart.

Secure Payment Transaction Guarantee

VISAAMEXDISCDINERSPayPal PayG Payshop

Choose Rapid Shipping at Checkout

Questions? Call 929-673-0062 · Mon–Fri 7–6 ↓ Full specifications

✓ Free Freight Nationwide

✓ Authorized Distributor

✓ Price-Match a Quote

✓ Manufacturer Warranty

✓ Bulk / Tax-Exempt Pricing

✓ Secure Checkout

Caldwell Dura-Lite Composite Adjustable Lifting Beams

From $1,518

Overview

The Dura-Lite Model 416 is a composite adjustable lifting beam: load hooks slide along the beam to match the load's pick points, and a lifting ring on top hangs from the crane hook. The composite construction does not rust and is non-conductive, which is why these beams turn up in wash-down, marine, and utility work.

Capacities run 1/4 to 3 ton by model, and each model carries one rating across its listed spread range; Caldwell publishes no derating for the 416. Hooks adjust in 3 or 6 in increments, with spread ranges from 12-24 in on the smallest beams to 120-144 in on the largest. The composite beam weighs a fraction of a steel equivalent, which leaves more of the crane's capacity for the load.

Each beam ships with its lifting ring and load hooks, proof tested with a certificate issued. The design complies with ASME B30.20, Design Category B, Service Class 4, and carries CE compliance. Pick capacity and spread range in the option list; pricing is quote-based, freight and lead time are confirmed at quote, and business leasing is available.

Key features

One WLL per model, 1/4 to 3 ton; no derating published across the spread range
Load hooks adjust along the beam in 3 or 6 in increments
Spread ranges from 12-24 in up to 120-144 in by model
Composite beam: non-conductive, corrosion-resistant, will not rust
Lighter than steel, preserving crane capacity for the load
Lifting ring and load hooks included
Proof tested with certificate issued
Complies with ASME B30.20, Design Category B, Service Class 4; CE compliant

Specifications

Capacity	1/4-3 ton
Brand	Caldwell Lifting Solutions
Shipping	Free · freight ETA at checkout

Ordering, trade & export

The answers trade buyers ask for before they order.

Can I order from outside the US?+

Yes. We ship freight worldwide and handle the export paperwork. Request a quote and we will confirm freight to your country and port.

Can I order tax-exempt or use a resale certificate?+

Yes. Send your resale or tax-exemption certificate before checkout and we will process the order tax-exempt.

Do I get a certificate with my item?+

Certified rigging and lifting products ship with the manufacturer certificate and proof-test documentation. Tell us if you need specific certs and we will confirm before you order.

Can you price-match or beat an existing quote?+

Yes. Send us a competitor written quote and we will match or beat it wherever we can. Use Request a Quote or call us.

When will I get my order?+

Ships in 5-10 business days; we confirm your freight ETA before dispatch. Freight transit time is added at checkout and we confirm a delivery ETA before your order ships.
