RUD VRS Starpoint, Metric Thread with Max. Length
★★★★★4.4 (48 reviews)Overview
The RUD VRS Starpoint, Metric Thread with Max. Length is built for industrial and material-handling work. Specifications include standard of DGUV tested/certified, wll of 0.4-4.5 ton. Request a quote for bulk pricing. Freight and lead time are confirmed at checkout, and business leasing is available.
Specifications
| Type | VRS STARPOINT boltable lifting point, 360-degree adjustable in force direction |
| Bolt | Non-detachable ICE-Bolt (patent steel, M6-M24), locknut + washer included |
| WLL basis | Manufacturer states WLL corresponds to the minimum WLL (worst-case loading direction) |
| Standard | DGUV tested/certified |
| Brand | RUD |
| Shipping | Free · freight ETA at checkout |
Specifications by size
Manufacturer-published figures for each of the 6 sizes in this range.
| Size | Model | Max Length | WLL | Weight |
|---|---|---|---|---|
| M10 x 70mm | 8600270 | 70mm | 0.4 t (880 lb) | 0.25 kg |
| M12 x 150mm | 8600271 | 150mm | 0.75 t (1,650 lb) | 0.44 kg |
| M16 x 120mm | 8600272 | 120mm | 1.5 t (3,300 lb) | 0.66 kg |
| M20 x 160mm | 8600273 | 160mm | 2.3 t (5,070 lb) | 1.1 kg |
| M24 x 140mm | 8600274 | 140mm | 3.2 t (7,050 lb) | 2.0 kg |
| M30 x 190mm | 8600275 | 190mm | 4.5 t (9,920 lb) | 3.75 kg |
