Tandemloc AS24 Series Single Fork Lifting Beams
★★★★⯨4.9 (32 reviews)- 2,000 lb WLL, proof tested to 125% and certified
- Three sizes fit fork widths from 1.75 to 7.25 in
- Swivel hook with safety latch; bolt-tightened mount
- ASME B30.20 and BTH-1, Design Category A, Service Class 0
Overview
The AS24 slips over a single forklift tine and puts a swivel hook under the truck: the fastest way to pick a slung load, a bucket bail, or a chained bundle with equipment already on the floor. A tightening bolt clamps the beam to the tine; no carriage attachment or second fork needed.
Working load limit is 2,000 lb on all three sizes, each proof tested to 125% of WLL and shipped with a certificate. The sizes fit fork widths of 1.75-3.25 in, 3.75-5.25 in, and 5.75-7.25 in, with a 2.25 in fork opening height; the hook swivels and carries a safety latch. Design meets or exceeds ASME B30.20 and BTH-1, Design Category A, Service Class 0.
Tandemloc manufactures the AS24 in the USA and finishes it in safety yellow; custom capacities and sizes can be quoted. Measure your tine width and thickness before ordering, then pick the matching size in the option list. Pricing is quote-based; shipping and lead time are confirmed at quote, and business leasing is available.
Key features
- 2,000 lb WLL on each size, proof tested to 125% with certificate
- Slips over one tine and clamps with a tightening bolt
- Swivel hook with safety latch
- Three sizes cover 1.75 to 7.25 in fork widths; 2.25 in fork opening height
- Meets or exceeds ASME B30.20 and BTH-1, Design Category A, Service Class 0
- Sandblasted, primed, and painted safety yellow
- Made in USA; custom capacities and sizes on request
Specifications
| Capacity | 2,000 lb |
| Brand | Tandemloc |
| Shipping | Free · freight ETA at checkout |
