Vestil Lightweight Winch Stacker Truck
★★★★⯨4.5 (65 reviews)- 350, 400, or 500 lb capacity by model
- Lift heights from 47 in to 122 in by mast
- Steel and aluminum build; hand-crank winch lift
- Counterbalanced, fixed, or adjustable straddle base
Overview
The A-LIFT is a hand winch stacker: an aluminum-and-steel lift truck light enough to roll through offices, labs, and stockrooms, with steel forks for positioning motors, fixtures, and boxed equipment where a powered stacker is overkill. A hand-crank winch raises the forks 1 in per full rotation, with a reversible handle and a hold-down device that secures the carriage for transport.
Capacity tracks the mast. Single-stage models lift 500 lb through a 47 in service range; two-stage HP models lift 400 lb to about 98 in; the extended EHP masts lift 350 lb to 122 in. Three bases cover the load: counterbalanced (no straddle legs), fixed straddle, and adjustable straddle. Steel forks measure 4 in wide by 1-3/4 in thick by 22 in long.
Units weigh 191 to 476 lb by model and roll on 8 in rear wheels with front swivel casters (5 and 4 in poly wheels on counterbalanced models). Pick base style and mast height in the option list. Pricing is quote-based; freight and lead time are confirmed at quote, and business leasing is available.
Key features
- Capacity by mast: 500 lb single-stage, 400 lb HP two-stage, 350 lb EHP extended
- Service ranges start as low as 1-1/4 in and reach 122 in on EHP masts
- Winch raises forks 1 in per crank rotation; reversible handle, carriage hold-down
- Three base styles: counterbalanced, fixed straddle, adjustable straddle
- Steel forks, 4 in wide x 1-3/4 in thick x 22 in long; forks invert for alternate height ranges
- Aluminum-and-steel construction, 191 to 476 lb unit weight
- Non-marking 8 in rear wheels with front swivel casters on straddle models
Specifications
| Capacity | 350-500 lb |
| Brand | Vestil |
| Shipping | Free · freight ETA at checkout |
